PRODUCT DESCRIPTION
[/et_pb_text][et_pb_text admin_label=”Circle CD is a patterned polished steel” _builder_version=”3.0.106″ background_layout=”light”]
Circle CD is a patterned polished steel finish that is applied mechanically to the surface of stainless steel sheets. These stainless polished steel finishes can be created with various visual effects. They are designed for architectural applications such as wall panels, elevator cabs, coping, and trim.
[/et_pb_text][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”3.0.106″ custom_margin=”0px|||” custom_padding=”0px|||”][et_pb_column type=”4_4″][et_pb_text admin_label=”SELECTING THE GRADE” _builder_version=”3.0.106″ background_layout=”light” module_class=”main-heading” custom_margin=”||0px|”]
SELECTING THE GRADE
[/et_pb_text][et_pb_text admin_label=”For the best performance over time,” _builder_version=”3.0.106″ background_layout=”light”]
For the best results over time, selection of the proper grade of Circle CD is important. Type 304, for most environments, is sufficient to prevent corrosion. Type 316 should be used near the seacoast. Low carbon versions of these grades (304L / 316L) should be used when parts are to be welded. see table i in data sheet for highlights of chemical analyses and properties. for extreme locations, e.g. near chemical plants or where steel may come into contact with salt water spray, different alloys will be required, subject to application review.
[/et_pb_text][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”3.0.106″ custom_margin=”0px|||” custom_padding=”0px|||”][et_pb_column type=”4_4″][et_pb_text admin_label=” POUNDS PER PIECE ” _builder_version=”3.0.106″ background_layout=”light” module_class=”main-heading” custom_margin=”||0px|”]
POUNDS PER PIECE
[/et_pb_text][et_pb_text admin_label=”Thickness (in.) x Width (in.) x Length (in.) x .292″ _builder_version=”3.0.106″ background_layout=”light”]
Thickness (in.) x Width (in.) x Length (in.) x .292
[/et_pb_text][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”3.0.106″ custom_margin=”0px|||” custom_padding=”0px|||”][et_pb_column type=”4_4″][et_pb_text admin_label=” AVAILABLE SIZES ” _builder_version=”3.0.106″ background_layout=”light” module_class=”main-heading” custom_margin=”||0px|”]
AVAILABLE SIZES
[/et_pb_text][et_pb_text admin_label=”See Table II. Coil widths. Inquire for length.” _builder_version=”3.0.106″ background_layout=”light”]
See Table II. Coil widths. Inquire for length.
[/et_pb_text][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”3.0.106″ custom_margin=”0px|||” custom_padding=”0px|||” module_class=”starlight-table”][et_pb_column type=”4_4″][et_pb_text admin_label=” FIRE RESISTANCE ” _builder_version=”3.0.106″ background_layout=”light” module_class=”main-heading” custom_margin=”||0px|”]
FIRE RESISTANCE
[/et_pb_text][et_pb_text admin_label=”Should a fire occur, Circle CD provides additional ” _builder_version=”3.0.106″ background_layout=”light”]
Should a fire occur, Circle CD provides additional protection as stainless steel has a melting point of 2750° F.
[/et_pb_text][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”3.0.106″ custom_margin=”0px|||” custom_padding=”0px|||”][et_pb_column type=”4_4″][et_pb_text admin_label=” FABRICATION & INSTALLATION ” _builder_version=”3.0.106″ background_layout=”light” module_class=”main-heading” custom_margin=”||0px|”]
FABRICATION & INSTALLATION
[/et_pb_text][et_pb_text admin_label=”Circle CD can be welded or soldered.” _builder_version=”3.0.106″ background_layout=”light”]
Circle CD can be welded or soldered. Preferably, use a grade of welding wire more noble than the work piece. Through use of shield gasses, formation of a heat tint scale may be avoided in lighter gauges. When scale does form, care must be taken to remove it through mechanical or chemical means. Circle CD is quite sensitive to alignment. Some projects may require the calculation of a border margin to ensure that panels with return legs that are installed next to each other are properly aligned. After soldering, flux residue must be removed. When installation is completed, remove any rust stains from tools/construction debris.
[/et_pb_text][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”3.0.106″ custom_margin=”0px|||” custom_padding=”0px|||”][et_pb_column type=”4_4″][et_pb_text admin_label=” MAINTENANCE ” _builder_version=”3.0.106″ background_layout=”light” module_class=”main-heading” custom_margin=”||0px|”]
MAINTENANCE
[/et_pb_text][et_pb_text admin_label=”Circle CD is designed to” _builder_version=”3.0.106″ background_layout=”light”]
Circle CD is designed to be essentially maintenance free. This polished steel will last for decades without requiring attention. Yet it may be appropriate at times to clean the surface in order to maintain its original appearance. Specific stainless steel agents are widely available. For general cleaning, any detergent or ammonia solution is effective. For stains, a sodium carbonate paste with a warm water rinse can be applied. For severe stains, you may use tri-sodium phosphate and caustic soda solutions. More difficult contaminants, like adhesive residue, will come off with pure acetone. Always avoid products containing chloride. Regularly clean out areas where debris may collect such as gutters.
[/et_pb_text][et_pb_text admin_label=”Download Data Sheet / More Bright Finishes” _builder_version=”3.0.106″ background_layout=”light”]
[/et_pb_text][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”3.0.106″ module_class=”product-image product-box”][et_pb_column type=”1_3″][et_pb_image _builder_version=”3.0.106″ src=”https://new.mirrormetals.com/wp-content/uploads/2018/09/circle-cd-72dpi-300x300px.jpg” show_in_lightbox=”on” url_new_window=”off” use_overlay=”off” always_center_on_mobile=”on” force_fullwidth=”off” show_bottom_space=”on” align=”left” custom_margin=”||20px|” /][et_pb_text admin_label=”More Embossed Finishes” _builder_version=”3.0.106″ background_layout=”light” header_3_font=”Merriweather||||||||” header_3_text_align=”center” header_3_font_size_last_edited=”on|desktop” header_text_align=”left” custom_margin=”||0px|” custom_padding=”||0px|” text_font=”Ubuntu||||||||” header_4_font=”Ubuntu||||||||”]
More Decorative Finishes
